26x14 -76 8*180 124mm
Available Size:
20x10 20x12 20x14 22x10 22x12 22x14 22x16 24x10 24x12 24x14 26x12 26x14 26x16 28x14 28x16 30x14 30x16
| CAR NAME | SIZE | ET | PCD | CB |
| GMC Sierra 2500 | 24*10 | -18 | 8*180 | 124.1 |
| 24*12 | -44 | 8*180 | 124.1 | |
| 24*14 | -76 | 8*180 | 124.1 | |
| 26*12 | -44 | 8*180 | 124.1 | |
| 26*14 | -76 | 8*180 | 124.1 | |
| GMC sierra 1500 | 24x12 | -44 | 6*139.7 | 78.1 |
| 24x14 | -76 | 6*139.7 | 78.1 | |
| 22*12 | -44 | 6*139.7 | 78.1 | |
| 26X14 | -76 | 6*139.7 | 78.1 | |
| 28X16 | -101 | 6*139.7 | 78.1 | |
| GMC sierra 3500 | 24*14 | -76 | 8*180 | 124.9 |
Bolt Pattern: 6×139.7mm
Center Bore: 78.1mm
Lug Stud: M14×1.5
Factory Offset: ET24 ~ ET31
Bolt Pattern: 8×180mm
Center Bore: 124.1mm
Lug Stud: M14×1.5
Factory Offset: ET35 ~ ET45
ECU tune improves throttle response, horsepower, torque and shift smoothness
Cold air intake + 3-inch cat-back exhaust for better sound and power
6.2L V8 support supercharger upgrade over 600HP
3.0L Duramax diesel tune for stronger towing torque
Stage 1–3 diesel tune gain big HP and torque for towing & off-road
4–5 inch turbo back exhaust for deep diesel tone
Upgrade intercooler, fuel injectors and fuel pump for high performance builds
2″ Leveling Kit: Perfect daily look, fits 33-inch tires
2.5–4″ Suspension Lift: Fit 35-inch tires, off-road ready
6″+ Extreme Lift: For 24×12 big wheel show truck
2.5–3.5″ Leveling Kit: Towing friendly, fits 35″ tires
4–6″ Full Lift: Heavy duty shocks, fits 37″ tires
8–10″ Extreme Lift: For 22×12 / 24×14 / 26×14 / 26×16 show builds
Upgrades: Adjustable upper control arms, dual steering stabilizer, heavy-duty leaf springs
18×9 / 20×10: ET+10 ~ +25 | Stock / 2″ Level
22×10: ET0 ~ -12 | 2.5–4″ Lift
24×12: ET-44 | 4–6″ Lift
Tire match: 33″ / 35″ A/T & M/T
20×10: ET-18 ~ -24 | 4″ Lift
22×12: ET-44 ~ -51 | 6″ Lift
24×14: ET-70 ~ -76 | 6–8″ Lift
26×14 / 26×16: ET-76 ~ -95 | 8–10″ Lift + Widebody
Rule: 24×14 and above forged wheels only
Custom GMC front mesh grille
Functional heat extraction hood
Wide fender flares for lifted big wheels
Steel front & rear bumpers + side steps
LED light bar, smoked headlights
Blackout package and custom badging
Daily Luxury: Level kit + 20/22″ wheels + A/T tires + intake exhaust tune
Off-Road Aggressive: 3–6″ lift + negative offset rims + M/T tires
Heavy Duty Tow: 2500/3500 level + diesel tune + 20×10 wheels
Show Truck: 6–10″ extreme lift + 24×14 / 26×16 deep dish forged rims
Hub ring: 1500 = 78.1mm ｜ 2500/3500 = 124.1mm
Lug nut: M14×1.5 extended conical seat
Torque: 1500 → 140–150 N·m ｜ 2500/3500 → 170–180 N·m
Big negative offset must match lift + flares to avoid rubbing
Lifted trucks need professional 4-wheel alignment
