26x12 -44 8x180 124.10
Available Size:
20x10 20x12 20x14 22x10 22x12 22x14 22x16 24x10 24x12 24x14 26x12 26x14 26x16 28x14 28x16 30x14 30x16
| SIZE | ET | PCD | CB |
| 28X16 | -101 | 6X139.7 | 78.1 |
| 24x12 | -44 | 6x139.7 | 78.1 |
| 24x14 | -76 | 6x139.7 | 78.1 |
| 22*12 | -44 | 6*139.7 | 78.1 |
| 26X14 | -76 | 6x139.7 | 78.1 |
PCD: 6×139.7mm
Center Bore: 78.1mm
Lug Stud: M14×1.5
Factory Offset: ET24 ~ ET31
Engines: 2.7L Turbo / 5.3L V8 / 6.2L V8 / 3.0L Duramax Diesel
PCD: 8×180mm
Center Bore: 124.1mm
Lug Stud: M14×1.5
Factory Offset: ET35 ~ ET45
Engines: 6.6L Duramax Diesel / 6.6L V8 Gasoline
ECU Tune: Better throttle response, +40–80 HP, improved fuel economy
Cold air intake + 3-inch cat-back exhaust for deeper sound & power gain
2.7L Turbo: Stage 2 tuning up to 350+ HP
6.2L V8: Supercharger upgrade reaches 600+ HP
3.0L Duramax: Tune + exhaust for higher torque & towing performance
6.6L Duramax Diesel: Stage 1–3 ECU tuning, big torque increase for towing & off-road
4–5 inch turbo-back exhaust for aggressive diesel tone
Upgrade intercooler, fuel injectors & high-pressure pump for high-power builds
Transmission tuning mandatory to handle extra torque
2" Leveling Kit: Level stance, fits 33" tires, daily friendly
2.5–4" Suspension Lift: Fox/Icon coilovers, fits 35" tires, off-road ready
6"+ Extreme Lift: For 24×12 large wheel show truck builds
2.5–3.5" Leveling Kit: Mild lift for 35" tires, towing optimized
4–6" Full Lift: Heavy-duty shocks, fits 37" tires
8–10" Extreme Lift: For 22×12 / 24×14 / 26×14 / 26×16 big wheel setups
Common upgrades: Adjustable upper control arms, dual steering stabilizer, heavy-duty leaf springs
18×9 / 20×9 / 20×10: ET+10 ~ +25 | Stock / Leveled
22×10: ET0 ~ -12 | 2.5–4" Lift
24×12: ET-44 | 4–6" Lift
Tire: 33×12.5R20 / 35×12.5R22 / 35×13.5R24
20×10: ET-18 ~ -24 | 4" Lift
22×12: ET-44 ~ -51 | 6" Lift
24×14: ET-70 ~ -76 | 6–8" Lift
26×14 / 26×16: ET-76 ~ -95 | 8–10" Lift + Widebody
Tire: 35/37/40 inch A/T & M/T tires
Note: 24×14 and above must use forged wheels
Custom GMC letter mesh grille
Functional heat extraction hood
Carbon fiber body trim
Wide fender flares for lifted big wheel builds
Steel front/rear bumpers + side steps
40-inch LED light bar, smoked headlights
Blackout package & custom badging
Daily Luxury: Level kit + 20/22" wheels + A/T tires + intake/exhaust + ECU tune
Off-Road Aggressive: 3–6" lift + negative offset wheels + M/T tires
Heavy Duty Tow: 2500/3500 level kit + 20×10 wheels + diesel tune
Show Truck: 6–10" extreme lift + 24×14 / 26×16 deep dish forged wheels
Use hub-centric rings to eliminate vibration
Wheel torque: 150 N·m (1500) / 175 N·m (2500/3500)
Big negative offset must match lift height to avoid fender rubbing
Lifted trucks require professional 4-wheel alignment
HD models prioritize high load rating for wheels
