26x12 -44 6x5.5 78.1
Available Size:
20x10 20x12 20x14 22x10 22x12 22x14 22x16 24x10 24x12 24x14 26x12 26x14 26x16 28x14 28x16 30x14 30x16
| CAR NAME | SIZE | ET | PCD | CB |
| Chevy Silverado 1500 | 22*14 | -76 | 6*139.7 | 78.1 |
| 24*14 | -76 | 6*139.7 | 78.1 | |
| 30*16 | -101 | 6*139.7 | 78.1 | |
| Chevy Silverado 2500 | 30x16 | -101 | 8*165.1 | 117 |
| 20x10 | -24 | 8x180 | 124.1 | |
| 2016 Chevy 3500 | 26x14 | -76 | 8x180 | 124.1 |
PCD: 6×139.7mm
Center Bore: 78.1mm
Lug Stud: M14×1.5
Factory Offset: ET20 ~ ET30
PCD: 8×180mm
Center Bore: 124.1mm
Lug Stud: M14×1.5
Factory Offset: ET35 ~ ET45
ECU Tune: Improve throttle response, increase HP & torque, optimize shifting
Cold air intake + 3" cat-back exhaust for deeper sound and power gain
6.2L V8 can upgrade supercharger for 600+ HP
3.0L Duramax: Tune + exhaust for better towing torque
Diesel Stage 1–3 ECU tune: Big HP & torque gain for towing & off-road
4"–5" turbo-back exhaust, upgraded intercooler
High-power build: Injectors + fuel pump upgrade for heavy performance
2″ Leveling Kit: Level stance, fits 33" tires, daily street use
2.5–4" Suspension Lift: Fits 35" tires, off-road ready
6"+ Extreme Lift: For 24×12 big wheel show builds
2.5–3.5" Leveling Kit: Fits 35" tires, towing friendly
4–6" Full Lift: Fits 37" tires, heavy-duty shocks
8–10" Extreme Lift: For 22×12 / 24×14 / 26×14 show truck setups
Upgrades: Adjustable upper control arms, dual steering stabilizer, heavy-duty leaf springs
18×9 / 20×10：ET0 ~ +20 | Stock / 2″ Level → 33" tires
22×10 / 22×12：ET-12 ~ ET-24 | 3.5–4" Lift → 35" tires
24×12：ET-44 | 4–6" Lift → 35/37" tires
20×10：ET-18 ~ ET-24 | 4" Lift → 35/37"
22×12：ET-44 ~ ET-51 | 6" Lift → 37"
24×14：ET-70 ~ ET-76 | 6–8" Lift → 37/40"
26×14/26×16：ET-76 ~ ET-95 | 8–10" Lift + Widebody
24×14 and larger must use forged rims for HD safety & load rating.
Custom Chevrolet / Silverado mesh grille
Functional heat extraction hood
Wide fender flares for lifted big wheels
Steel front & rear bumpers + side steps
40" LED light bar, smoked headlights
Blackout trim package & custom badging
Daily Luxury：2″ Level + 20/22" rims + AT tires + intake/exhaust tune
Off-Road Aggressive：4–6" lift + negative offset rims + MT tires
Heavy Duty Tow：2500 level kit + diesel tune + 20×10 wheels
Show Truck：6–10" extreme lift + 24×14 / 26×14 deep dish forged rims
Hub ring: 1500 = 78.1mm｜2500 HD = 124.1mm
Lug nut: M14×1.5 extended conical seat
Torque: 1500 → 140–150 N·m｜2500 → 170–180 N·m
Big negative offset needs lift + flares to avoid rubbing
Lifted trucks require professional 4-wheel alignment
