26*16 -90 8*165.1 121.3
Available Size:
20x10 20x12 20x14 22x10 22x12 22x14 22x16 24x10 24x12 24x14 26x12 26x14 26x16 28x14 28x16 30x14 30x16
| CAR NAME | SIZE | ET | PCD | CB |
| Dodge RAM 2500 | 22x12 | -50 | 8*165.1 | 121.3 |
| 24X14 | -76 | 8*165.1 | 121.3 | |
| 26X14 | -76 | 8*165.1 | 121.3 | |
| 26*16 | -90 | 8*165.1 | 121.3 | |
| Dodge ram 3500 | 24x14 | -76 | 8*165.1 | 121.3 |
PCD: 8×165.1mm (8×6.5")
Center Bore: 121.3mm
Wheel Studs: M14×1.5
Factory Offset: ET30 ~ ET40
Engine Options
6.7L Cummins Turbo Diesel
6.4L HEMI V8 Gasoline
ECU Stage 1 / 2 / 3 Tune
Boost horsepower +60–180HP, torque +150–300lb-ft; improve throttle response, towing power and fuel efficiency.
Intake & Intercooler
High-flow cold air intake + upgraded intercooler, reduce heat soak, maintain stable power.
Exhaust System
4"–5" turbo-back straight pipe exhaust, deep aggressive diesel tone, better airflow.
Advanced Upgrades
Upgraded fuel injectors, high-pressure fuel pump, compound turbo kit; easily reach 500HP+ / 1100lb-ft+.
2.5–3.5" Leveling Kit
Level front & rear, fit 35” tires; perfect for daily driving and towing.
4–6" Full Suspension Lift
BDS / Fox / Rancho coilovers; fit 37” tires, improve off-road performance.
8–10" Extreme Lift
For 22×12 / 24×14 / 26×14 / 26×16 big wheel show builds.
Common Upgrades
Adjustable upper control arms, dual steering stabilizer, heavy-duty leaf springs, bump stops, steel skid plates.
22×12: ET-44 ~ ET-51 | 4"+ Lift | Tire: 35×12.5R22 / 37×13.5R22
24×14: ET-70 ~ ET-76 | 6"+ Lift | Tire: 37×15.5R24 / 40×15.5R24
26×14: ET-76 ~ ET-84 | 8"+ Lift | Tire: 40×15.5R26
26×16: ET-88 ~ ET-96 | 10"+ Lift + Widebody | Tire: 40×16R26
Rule: 24×14 and above must use forged wheels for heavy load safety.
Custom RAM letter mesh grille
Functional heat extraction hood
Wide fender flares for lifted big wheel setup
Steel front & rear bumpers + side steps / rock sliders
40" LED light bar, A-pillar ditch lights, smoked headlights
Blackout trim package & custom badging
Daily & Towing: 2.5" level + 22×12 wheels + 35" A/T tires + Stage 1 Cummins tune
Off-Road Aggressive: 6" lift + Fox suspension + 24×14 wheels + 37" M/T tires + 5" exhaust
Show Truck: 10" extreme lift + 26×16 deep dish forged wheels + widebody fenders
Hub Centric Ring: 121.3mm
Lug Nut: M14×1.5 extended conical seat
Wheel Torque: 170–180 N·m
Large negative offset requires lift + flares to avoid rubbing
Lifted trucks must do professional 4-wheel alignment
